Mitel 5304 VoIP Phone



The 5304 IP Phone is a cost-effective entry-level display phone that provides access to the features and applications enabled by Mitel’s IP communications platforms. This two-line, dual-port IP phone with a 20-character backlit display supports both SIP and MiNet protocols and works behind a range of Mitel platforms and can be easily deployed as a Teleworker phone.

It is specifically suited to areas where a small footprint is required: cruise ship cabins, hotel guest room phones, university dorms, classrooms or beside a cash register in the retail environment.



Features of the 5304 IP Phone include:
■40-character backlit display (with auto-dimming)
■2 Lines with LED indication: 1 prime line and 1 programmable key with LED
■8 Programmable keys: speed dials, features access codes, paging, conferencing, voicemail access etc.
■Paging & page receive capability
■Direct page & group page support
■Dual mode: MiNet and SIP support
■Incoming call visual indication
■Message waiting indication
■Adjustable volume/ringing controls
■Wall-mountable (optional)
■Multiple powering options (802.3af compliant)
■ADA-compliant (HAC handset)
■Small footprint (26.5 cm x 10 cm or 10.5 in x 4 in)
■Designed for power conservation: reduces power consumption for overall energy savings
■Supported on Mitel Communications Director (MCD), Mitel SX-200 IP Communications Platform (CP), Mitel 5000 Communications Platform (CP), and Mitel Border Gateway (MBG)
